Mecánica Prisma offers a wide range of quality products for the automation of valves and fluid conduction processes

heroBannerComponent

Overview

richTextComponent

Brand Product Listing

<p>If you require further assistance please contact the support centre on +44 (0) 33 000 22 223</p>

The following product cannot be added to your basket

productListingWithFiltersComponent

ThreadGender

ThreadSize

ThreadType

Brand

Material

MaximumworkingPressurebar

Seal

WorkingTemperature

Function

Type

ToSuit

Angle

BodyMaterial

Size

ActuatorMaterial

ValveMaterial

BodySizeInch

WorkingTorqueNm

SeatMaterial

RotationAngle

1" SA T PORT

1" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Single Acting, T Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

Features: 0-90° rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 25 to 1180 Nm at 6 bar. Single acting torques from 11.3 to 491.6 Nm end of spring. Stainless steel body. ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T80°C Db certification. Suitable for use in a SIL safety loop. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.

PRISMA SS PI40 DA ACTUATOR

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL2 Approved, Stainless Steel, 5.3 Litres per Minute Air Consumption Opening, 5.3 Litres per Minute Air Consumption Closing, 1180 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

Features: 0-90° rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 28.5 to 269.2 Nm at 6 bar. Single acting torques from 12.7 to 195.7 Nm end of spring. Rilsan and epoxy coated aluminium body. ATEX II 2G Ex h IIB T6 Gb / II 2D Ex h IIIC T80°C Db certification. Suitable for use in a SIL safety loop. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.

PRISMA PA25 DA ACTUATOR C/W LAPS

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Epoxy Coated Aluminium, 1.5 Litres per Minute Air Consumption Opening, 2.02 Litres per Minute Air Consumption Closing, 290 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

Features: 0-90° rotation angle to pilot ball, butterfly and plug valves.Double acting torques from 17 to 5043 Nm at 6 bar. Single acting torques from 6.7 to 1769 Nm end of spring. Rilsan and epoxy coated aluminium body. ATEX II 2G Ex h IIB T6 Gb / II 2D Ex h IIIC T80°C Db certification. Suitable for use in a SIL safety loop. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.

PRISMA PA10 DA ACTUATOR

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Epoxy Coated Aluminium, 0.35 Litres per Minute Air Consumption Opening, 0.45 Litres per Minute Air Consumption Closing, 71 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

1/4" DA L PORT

1/4" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Double Acting, L Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

Features: 0-90° rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 17 to 165.5 Nm at 6 bar. Single acting torques from 6.7 to 65.8 Nm end of spring. Polyamide body. ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T80°C Db certification. SIL3 rated. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.

PRISMA PLASTIC PPWS SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Polyamide, 0.075 Litres per Minute Air Consumption Opening, 0.05 Litres per Minute Air Consumption Closing, 10.3 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

PRISMA PAW DA ACTUATOR

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Epoxy Coated Aluminium, 0.075 Litres per Minute Air Consumption Opening, 0.11 Litres per Minute Air Consumption Closing, 17 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

PRISMA PA60S SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL1 Approved, Epoxy Coated Aluminium, 19.5 Litres per Minute Air Consumption Opening, 20.7 Litres per Minute Air Consumption Closing, 2074 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

1.1/4"BSP D/ACT T-PORT ST/ST BALL VALVE

1.1/4" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Double Acting, T Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

PRISMA SS PI30S SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Stainless Steel, 2.05 Litres per Minute Air Consumption Opening, 1.9 Litres per Minute Air Consumption Closing, 289.3 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

1.1/2" SA T PORT

1.1/2" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Single Acting, T Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

1/4" SA L PORT

1/4" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Single Acting, L Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

Valve: 3 piece full bore ball valve, stainless steel body, cavity filled PTFE seals, OD butt weld ends. Actuator: Rilsan coated aluminium body, 1/4" BSP female ports. Sized based on 10 bar pilot air and wet non-abrasive duty at +90°C. Other end connections on request: RJT, IDF, Clamp. Both the valve and actuator are ATEX approved. Please contact technical sales for the full ATEX classification.

DO NOT USE

3" Outside Diameter, Pneumatic Actuated Stainless Steel Sanitary 2 Way, Single Acting Actuation, Working Temperature, 0°C to +70°C, Maximum Working Pressure 10 Bar, Prisma

PRISMA PA00S SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Epoxy Coated Aluminium, 0.15 Litres per Minute Air Consumption Opening, 0.18 Litres per Minute Air Consumption Closing, 15.8 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

PRISMA PA10 DA ACTUATOR C/W LAPS

PRISMA PLASTIC PP20S SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Polyamide, 0.8 Litres per Minute Air Consumption Opening, 1.15 Litres per Minute Air Consumption Closing, 99.7 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

PRISMA PA00S SA ACTUATOR C/W LAPS

3/4" OD CAV FILL BALL VALVE SGLE ACTING

3/4" Outside Diameter, Pneumatic Actuated Stainless Steel Sanitary 2 Way, Single Acting Actuation, Working Temperature, 0°C to +70°C, Maximum Working Pressure 10 Bar, Prisma

PRISMA PA30 DA ACTUATOR C/W LAPS

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL2 Approved, Epoxy Coated Aluminium, 2.05 Litres per Minute Air Consumption Opening, 3 Litres per Minute Air Consumption Closing, 469 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

2" DA L PORT

2" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Double Acting, L Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

PRISMA PLASTIC PP20 DA ACTUATOR

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Polyamide, 0.8 Litres per Minute Air Consumption Opening, 1.15 Litres per Minute Air Consumption Closing, 165.5 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

3/4" DA T PORT

3/4" BSP Parallel Female, Pneumatic Actuated Stainless Steel 3 Way Valve, Double Acting, T Ported, Working Temperature, -20°C to +80°C, Maximum Working Pressure 69 Bar, Prisma

PRISMA SS PI40S SA ACTUATOR

Single Acting Actuator, 0-90° Rotation Angle, ATEX, SIL2 Approved, Stainless Steel, 5.3 Litres per Minute Air Consumption Opening, 5.3 Litres per Minute Air Consumption Closing, 688.3 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

PRISMA PA20 DA ACTUATOR C/W LAPS

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Epoxy Coated Aluminium, 0.8 Litres per Minute Air Consumption Opening, 1.15 Litres per Minute Air Consumption Closing, 165.5 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma
